Portable O3 gas detector has LCD display function and rechargeable lithium battery powered digital ozone gas monitor. Portable gas detectors and alarms from Gas Monitor Point for the detection of levels of Ozone (O3).
OT131 gas detector is a pump-suction ultra-high sensitivity gas leakage detector. Electrochemistry sensor is more suitable for locating and detecting leakage gas. It is compact, easy to operate, easy to carry, and can also be attached with a flexible probe, comfortable handle. It also can show a unique concentration curve.
|
Gas |
Measuring range |
Optional range |
Resolution |
Response time |
|
EX |
0-100%LEL |
0-100%VOL (infrared) |
1%LEL/1%VOL |
≤15second |
|
O2 |
0-30%VOL |
0-30%、0-100%VOL |
0.1%/0.01%VOL |
≤15second |
|
H2S |
0-100PPM |
0-50、200、1000PPM |
0.1/1PPM |
≤15second |
|
CO |
0-1000PPM |
0-500/2000/5000PPM |
0.1/1PPM |
≤15second |
|
NO2 |
0-20PPM |
0-50、1000PPM |
0.1/1PPM |
≤20second |
|
Natural gas |
0-100%LEL |
0-100%VOL |
1%LEL/1%VOL |
≤15second |
|
NOX |
0-20PPM |
0-50、1000PPM |
0.1/1PPM |
≤20second |
|
CH4 |
0-100%LEL |
0-100%VOL |
1%LEL/1%VOL |
≤15second |
|
CO2 |
0-5000PPM |
0-1%、5%、10%VOL (infrared) |
1PPM/0.01%VOL |
≤20second |
|
NO |
0-250PPM |
0-500、1000PPM |
1PPM |
≤20second |
|
N2 |
0-100%VOL |
0-100%VOL |
0.1%VOL |
≤15second |
|
Alcohol |
0-100%LEL |
0-100%LEL |
1%LEL/1%VOL |
≤15second |
|
SO2 |
0-20PPM |
0-50、1000PPM |
0.1/1PPM |
≤20second |
|
CL2 |
0-20PPM |
0-10、50、100PPM |
0.1PPM |
≤20second |
|
dichlorosilane |
0-20PPM |
0-20、100PPM |
1/0.1PPM |
≤20second |
|
NH3 |
0-100PPM |
0-50、500、1000PPM |
0.1/1PPM |
≤20second |
|
Silicon tetrachloride |
0-20PPM |
0-20、100PPM |
1/0.1PPM |
≤20second |
|
H2 |
0-1000PPM |
0-40000PPM |
1/10PPM |
≤20second |
|
PH3 |
0-20PPM |
0-20、1000PPM |
0.1/1PPM |
≤20second |
|
HCL |
0-20PPM |
0-20、50、100PPM |
0.1/1PPM |
≤20second |
|
Acrylonitrile |
0-100PPM |
0-100PPM |
1PPM |
≤20second |
|
TVOC |
0-100PPM |
0-100PPM |
1PPM |
≤20second |
|
CLO2 |
0-50PPM |
0-10、100PPM |
0.1PPM |
≤20second |
|
HCN |
0-50PPM |
0-100PPM |
0.1PPM |
≤20second |
|
ETO |
0-10PPM |
0-100、1000PPM |
1PPM |
≤20second |
|
O3 |
0-10PPM |
0-20、100PPM |
0.01/0.1PPM |
≤20second |
|
CH2O |
0-20PPM |
0-50、100PPM |
0.1/1PPM |
≤20second |
|
F2 |
0-10PPM |
0-1、10PPM |
1/0.1PPM |
≤20second |
|
HF |
0-10PPM |
0-1、10、50、100PPM |
0.01/0.1PPM |
≤20second |
|
Xylene, toluene |
0-20PPM |
50、100PPM |
0.1/1PPM |
≤20second |
|
Stench |
0-100PPM |
0-100PPM |
1PPM |
≤20second |
|
For unlisted gas, please contact our sales department |
||||
|
Detection gas |
Ozone(O3) |
| Range | 10ppm/20ppm/50ppm/100ppm |
| Resolution | 0.01ppm/0.1ppm |
|
Detection method |
pump suction |
|
Detection principle |
electrochemistry |
|
Display |
color LCD display |
|
Accuracy |
3% FS |
|
Interface definition |
U3 port (USB) |
|
Power source: |
3.7V 2000mAh |
|
Power supply method |
Lithium ion rechargeable battery |
|
Alarm |
Three-level alarm of sound and light vibration |
|
Operating environment |
temperature -10 ℃ ～ 50 ℃; humidity: ≤95% RH (no condensation)
|
|
Storage environment |
temperature -40 ℃ ～ 70 ℃; humidity: ≤95% RH (no condensation) |
|
:Response time |
<10s |
|
Sensitivity |
1PPM / 1% LEL |
|
Explosion-proof grade |
intrinsically safe |
|
Security level |
Ex ib IIB T3 Gb |
|
Alarm point |
adjustable |
|
Standby time |
combustible gas> 8h toxic gas about 300 hours |
|
Weight |
500g |
|
Size |
(254 × 68 × 48) mm (excluding probe rod) |
|
Leak detection instrument |
natural diffusion type, with extended flexible probe, PPM and% LEL display simultaneously |
|
Detection instrument |
built-in pump suction detection method, double buzzer prompt and its growing light indication |
